Network Slicing – A Service-Oriented Network Architecture for Industry Verticals

By Varini Gupta Samsung Research Institute India - Bangalore
By Dongeun Suh Samsung Research
By Deepanshu Gautam Samsung Research Institute India - Bangalore

As operators around the world roll out 5G technology, a fundamental change to network architectures has taken place: networks of today are more resilient, flexible and extensible. More and more industry verticals are being integrated with the 5G networks, and as this happens, there is one issue less to worry about – the fear of monolithic network and network-wide downtime!

Gone are the days when every new service introduced in the network had to be planned months, if not years, ahead. Several rounds of validations were done in mock environment to ensure existing services won't be impacted. Millions were invested in hot-standby systems yet operators still shivered at the prospect of software misbehavior. 5G networks, on the other hand, are more 'service-based', where each service can be deployed on a sub-network isolated from others. Introducing a new service doesn't require and won't cause a downtime on the entire network.

Network slicing is essentially the ability to divide your network into individual compartments, each curated to provide these specialized services. There could be one slice for providing service to a logistics enterprise, which wants to use the operator's network to track its fleet of trucks at any point of time, while another slice for retail customers interested to use operator's network for voice and data. Apart from providing different levels of security, e.g., due to enterprises not wanting their data to pass through same “compartment” as retail customers for want of data-confidentiality, each compartment could also provide a different level of quality of service (QoS) and/or availability. Moreover, each such compartment can be commissioned or decommissioned, augmented or decreased in size independent of other compartments present in the same network.

Samsung has been actively participating in standardizing network slicing work in 3GPP since initial phases of 5G. In particular, essential system enhancements that improve slice availability and experiences for users have been led by Samsung. Also, Samsung is currently leading the standardization work which aims to realize the automated management of network slices.

Evolultion of Slicing in 3GPP Standards

APN (Access Point Name) was probably earliest form of network slicing in a mobile network, which allowed operators to divide their networks according to service requirements. Each distinct service could be identified by a separate APN-name, and users would connect to their compartment (APN) depending on the service they wanted to consume. This form of slicing, however, required common network functions (NFs)’ resources shared among multiple APNs, and thus services were not "fully" isolated.

Figure 1.  Network slicing evolution in 3GPP

The 5G network architecture of 3GPP Release-15 was a great leap forward, where network slicing became fundamental to network design. Every NF is identified by a slice identifier it belongs to; each base station is configured with the slices it serves and every user’s subscription contains information on slices it is allowed to access. The user can subscribe to multiple services, which may be provided on isolated slices within the network. The user equipment (UE) is additionally configured with the information that helps select the right slice for its application traffic. In addition, standardized network slice life-cycle management procedures were developed using service-based architecture, leading to a near-perfect, end-to-end network-slicing architecture.

In Releases-16 and 17, 3GPP continued to address a number of practical deployment gaps based on feedback from the industry. Restricted (and limited) access to a slice, steering users to a cell supporting slices-of-interest have been some of such focus areas. Further enhancements are being considering in Release-18 (5G Advanced), including service continuity and improved network slice management.

Technical Know-How

A network slice deployment comprises UE (User Equipment), NG-RAN, control plane (e.g., AMF, PCF, SMF) and user plane (e.g., UPF) network functions.

Each network slice is identified by an S-NSSAI containing a Slice Service Type (SST) that identifies the service for which a network slice is suitable. A network operator can use either standardized SST values (i.e., 1 for enhanced mobile broadband, 2 for ultra-reliable low latency communications, 3 for massive IoT, 4 for V2X, 5 for High performance machine type communications) or non-standardized SST values that can be locally defined.

Figure 2.  An example of network slice deployments where URLLC slice and eMBB slice are deployed

The UE is configured with rules (USRP - UE Route Selection Policy) that allow it to select an S-NSSAI based on the application it wishes to use (depending on, e.g., QoS requirements of the application), as illustrated in the example. The UE has two PDU sessions, where one is established via S-NSSAI#1 (URLLC slice) towards the Data Network Name (DNN) of internet while the other is established via S-NSSAI#2 (eMBB slice) towards the same DNN. When a UE needs to send traffic of App1, the UE finds the matching traffic descriptor in the URSP rule and selects the PDU session according to the corresponding route selection descriptor (e.g., PDU session of S-NSSAI#1 and DNN of internet).

Network Slice Access & Admission Control

Network slice-specific authentication and authorization (NSSAA) is a feature that enables a 3rd party application provider who contracted for a specific slice to authorize and authenticate UEs for the network slice. In order to have an S-NSSAI subject to NSSAA to be allowed, a UE needs grant from 3rd party server based on a pre-provisioned credential for the S-NSSAI.

Network slice admission control (NSAC) is a feature to control and monitor the number of registered UEs per S-NSSAI and the number of PDU sessions per S-NSSAI. During the procedure of allowing S-NSSAI to a UE or allowing a new PDU session in S-NSSAI, the network checks whether the maximum number of UEs for the S-NSSAI or the maximum number of PDU sessions for the S-NSSAI have been already reached, respectively, and the network allows only when the maximum values have not been reached yet. Also, the current number of UEs or PDU sessions in a network slice can be exposed to a 3rd party for further customization.

Network Slicing based on Different Spectrum Usage

Slice-aware Radio Access Network (RAN), where an operator can manage radio spectrum per network slice, is an important standard feature led by Samsung. For example, an operator could use eMBB service on higher frequency band and IoT on a low frequency band, respectively.

Figure 3.  Cell re-selection or redirection

Let’s consider an example of gNB (base station) providing network connectivity via carrier frequencies f1 and f2. The cell on frequency f1 supports only S-NSSAI = 1 whereas the cell on frequency f2 supports S-NSSAIs = 1, 2. If a user were to request S-NSSAI = 1,2 while latching on cell of frequency f1, the mechanisms developed in Rel-17 allow it to be redirected to cell of frequency f2. Alternatively, UE could also be configured with information to directly re-select to the cell of frequency f2.

Network Slice Management Aspects

Standardizing the management aspect of network slicing is crucial for the large scale adoption of the slicing feature. Use case such as NaaS (Network-as-a-service) enables consumers (internal or external) to request for a slice allocation at run-time. This requires exposing a standardized management interface for consumers to use. The same interface also enables consumers to monitor the performance of the slices assigned to them and request for a particular SLA (Service Level Agreement) to be maintained.

3GPP has developed mechanisms for end-to-end lifecycle management (LCM) and configuration of a network slice. The LCM of network slice includes on-demand slice instantiation, modification, termination and performance assurance.

Figure 4.  Provisioning (configuration, quota management, LCM)

The GSMA Generic Slice Template (GST) is used to capture the requirements for such slice management. These requirements are translated into the requirements for RAN, transport and the core network. GST attributes can be classified in two major categories: configurable attributes and non-configurable attributes. The configuration attributes are those attributes which will get translated into configuration parameters for network functions. The configuration parameters are enforced by the individual network functions at run-time. The non-configurable parameters will be enforced by the management plane during slice provisioning.

Performance Assurance

Performance Assurance (PA) defines the measurements and the collection mechanisms for the purpose of network monitoring and management. Two alternatives have been defined for the PA by 3GPP: a dedicated operation-based approach where dedicated operations have been defined to request/receive/collect the required performance measurements, and a Network Resource Model (NRM)-based approach where NRM control fragments are defined to enable the functionality of requesting/receiving/collecting the required performance measurements.

Figure 5.  Performance Assurance (collection, measurements/KPI)

Further, 3GPP defines mechanisms to assure the SLA requirements for network slices. This is enabled by the ACCL (Assurance Closed Control Loop) mechanism. An ACCL contains four steps: Monitor, Analyse, Decide and Execute. The slice performance is monitored by collecting the various management data including performance measurements, alarms, trace and QoE (Quality of Experience) data. The data is then analysed using AI/ML methodologies to check if the slice SLA is fulfilled or will be fulfilled in future. The root cause analysis is performed to understand the cause of the SLA deterioration, if any. Once the root cause in ascertained the corrective actions are decided and executed to keep up the slice SLA guarantee. Strict SLS assurance for a service can be provided using ACCL for a high-valued vertical customer present in a particular location.


With the introduction of Network Slicing in 5G, it is now possible for operators to leverage a fully-flexible, service-oriented end-to-end network architecture for industry verticals. With the recently initiated work on 5G Advanced, 3GPP continues to exploit this concept further to improve the ease of deployment and fill gaps reported by industry. Some of the focus areas include: allowing selection of roaming partner (by the UE) based on slices supported, service continuity when existing slice cannot meet the agreed SLAs, support of temporary slices, e.g., during a stadium event, etc. Additionally, it is expected that the network slice management would become more robust and automated requiring no human intervention (zero-touch network slice management/automation). The standardized mechanism for performance data collection would enhance to the extent of collecting data for a particular location, domain, traffic-type, etc. and then taking automated decision to meet the SLAs.

Samsung believes network slicing to be an essential feature for 5G and 5G Advanced deployments, which enables customization of networks for heterogeneous needs of the emerging industry verticals, and the end consumers.


1. 3GPP SA2: 3GPP TS 23.501: "System architecture for the 5G System (5GS)"

2. 3GPP SA5: 3GPP TS 28.533: “Management and orchestration; Architecture framework”

3. 3GPP RAN2: 3GPP TS 38.300: “NR; NR and NG-RAN Overall description; Stage-2”

4. Samsung’s Network Slicing Powers Profitable 5G

Acknowledgements: The authors would like to acknowledge the contributions from Sangsoo Jeong, Suresh Chitturi and the entire 3GPP System Standards team at Samsung Research.
